Description
| CPU | LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors. L3 cache varies with CPU. (Refer to “CPU Support List” for more information.) |
| Chipset | Intel® Z790 Express Chipset |
| Memory | – Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 memory modules – 4 x DDR5 DIMM sockets supporting up to 192 GB (48 GB single DIMM capacity) of system memory – Dual channel memory architecture – Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) – Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules – Support for Extreme Memory Profile (XMP) memory modules (Refer to “Memory Support List” for more information.) |
| Onboard Graphics | Integrated Graphics Processor-Intel® HD Graphics support: 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3. ** Support native HDMI 2.1 TMDS compatible ports. 1 x DisplayPort, supporting a maximum resolution of 4096×2304@60 * Support for DisplayPort 1.2 version and HDCP 2.3 (Graphics specifications may vary depending on CPU support.) |
| Audio | Realtek® ALC1220 CODEC * The back panel line out jack supports DSD audio. High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. Support for S/PDIF Out |
| LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless Communication | – Intel® Wi-Fi 6E AX211 (PCB rev. 1.0): WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.3 Support for 11ax 160MHz wireless standard – Realtek® Wi-Fi 6E RTL8852CE (PCB rev. 1.1): WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.3 Support for 11ax 160MHz wireless standard (Actual data rate may vary depending on environment and equipment.) |
| Expansion Slots | CPU: 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4) |
| Storage Interface | CPU: 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) Chipset: 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB) 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB) 6 x SATA 6Gb/s connectors RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices |
| USB | Chipset: 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2×2 support 1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel Chipset+2 USB 2.0 Hubs: 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header) Chipset+2 USB 2.0 Hubs: 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers) |
| Internal I/O Connectors | – 1 x 24-pin ATX main power connector – 1 x 8-pin ATX 12V power connector – 1 x 4-pin ATX 12V power connector – 1 x CPU fan header – 1 x water cooling CPU fan header – 3 x system fan headers – 1 x system fan/water cooling pump header – 2 x addressable LED strip headers – 2 x RGB LED strip headers – 3 x M.2 Socket 3 connectors – 6 x SATA 6Gb/s connectors – 1 x front panel header – 1 x front panel audio header – 1 x USB Type-C® header, with USB 3.2 Gen 2 support – 1 x USB 3.2 Gen 1 header – 2 x USB 2.0/1.1 headers – 2 x Thunderbolt™ add-in card connectors – 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) – 1 x serial port header – 1 x reset button – 1 x Q-Flash Plus button – 1 x Clear CMOS button – 1 x reset jumper |
| Back Panel Connectors | – 1 x USB Type-C® port, with USB 3.2 Gen 2×2 support – 1 x USB 3.2 Gen 2 Type-A port (red) – 4 x USB 3.2 Gen 1 ports – 4 x USB 2.0/1.1 ports – 2 x SMA antenna connectors (2T2R) – 1 x HDMI 2.0 port – 1 x DisplayPort – 1 x RJ-45 port – 1 x optical S/PDIF Out connector – 2 x audio jacks |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | – Voltage detection – Temperature detection – Fan speed detection – Water cooling flow rate detection – Fan fail warning – Fan speed control * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install. |
| BIOS | – 1 x 256 Mbit flash – Use of licensed AMI UEFI BIOS – PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | – Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. – Support for Q-Flash – Support for Q-Flash Plus – Support for Smart Backup |
| Bundled Software | – Norton® Internet Security (OEM version) – LAN bandwidth management software |
| Operating System | – Support for Windows 11 64-bit – Support for Windows 10 64-bit |
| Form Factor | – Micro ATX Form Factor; 24.4cm x 24.4cm |
Specification may change without further notice.
