Description
Product Specifications
- Backlight Module OC Model LC238LF1F / BOE
- Panel Type Fast IPS
- Flat/Curve Flat
- Curved Ratio /
- Aspect Ratio 16:9
- Screen Size 23.8″
- Display Area（H*V）04(H) × 296.46(V)
- Panel Resolution 1920*1080
- Refresh Rate OC 165HZ
- Overfrequency NA
- Backlight type ELED
- Brightness Defaulted(TYP) 250 (±30）
- Max(TYP) 280 (±30）
- Default Color Temperature 7500K
- Contrast Ratio Static State 1000:1
- Dynamic State Millions
- Pixels 16.7M(RGB 8bit)
- “Colour Gamut
- (Coveraged)” sRGB 106%
- NTSC 72%
- HDR NA
- View Angle（H/V） 178°/178°
- Response Time OC （GTG） 1MS
- OD Accelerate Response MPRT 0.5MS
- Eletronics Chipset RTD2556
- I/O Prts（Standard） HDMI+DP+Audio out
- Port1 DC 12V 3A
- Port2 HDMI2.0
- Port3 DP1.2
- Port4 Audio out
- MPRT yes
- Speaker N/A
- Power Input DC 12V3A
- Power Supply External power Adapter
- Power Consumption AC Input Power 36W Max
- Stand-by Power Consumption（Max） ≤0.32w
- Indicator Light Mode Power on:Blue(LED)
- Structure Appearance Color Black
- RGB light / Gaming Light N/A
- Unit W/stand 541*425*172 mm
- Unit W/O stand 541*326*41mm
- Packing Size 615*410*125 mm
- Net Weight 3.2kg
- Gross Weight 4.9kg
- VESA Size(WxH) VESA Demension 75*75 mm
- Vesa Mount Method Screw
- Stand Functions Angle （Forerake /Back-Lean） Forerake :5° Lean Back:15°
- Up and Down（Vertical） N/A
- Swivel（L/R） N/A
- Pivot N/A
- Software OSD Key Control Mode Five button
- OSD Manue Style Common Black OSD
- Language Menu 10 Countries Language(Defaut:English)
- Main Functions Color Temperature(Cold,Warm,User)
- Low Blue Light Control
- 6 Contextual Models
- DCR
- Multiple-Language Menu
- Backlight ajustment w/o flicker
- FPS/RTS Game Mode with 1 key-switch
- GAME PLUS
- Adaptive-Sync / G-sync compatible
- HDR Function
- Over Drive
- MPRT
- Storage and working Environment Working Temperature -20ºC~60ºC
- Storage Temperature 0ºC~40ºC
- Working Humidity 10~85%RH
- Storage Humidity 5~90%(No Freezing under 40ºC ）
- Altitudes ≤5000m
- Assessory List USER MANUAL yes
- Energy Label N/A
- Power Adapter yes
- STAND SCREWS yes
- DP cable yes
