Upgrade your PC cooling with the Deepcool LE520 240mm AIO Liquid Cooler. Featuring Anti-Leak Tech for worry-free operation, it keeps your system cool and quiet. High-performance ARGB fans ensure optimal airflow, while the sleek black design adds a touch of style to your setup. Stay cool, stay efficient.

Product Specifications

• Brand: Deepcool
• Model: LE520
• Color: Black
• Application for:
• Intel: LGA1700/1200/1151/1150/1155
• AMD: AM5/AM4
• Net Weight: 1238 g
• Radiator Dimensions: 282×120×27 mm
• Radiator Material: Aluminum
• Tube length: 410 mm
• Pump Dimensions: 91×80×52 mm
• Pump Speed: 2400 RPM±10%
• Pump Noise: 17.8 dB(A)
• Pump Connector: 3-pin
• Pump Rated Voltage: 12 VDC
• Pump Rated Current: 0.2 A
• Pump Power Consumption: 2.4 W
• Fan Dimensions: 120×120×25 mm
• Fan Speed: 500~2250RPM±10%
• Fan Airflow: 85.85 CFM
• Fan Air Pressure 3.27 mmAq
• Fan Noise ≤32.9 dB(A)
• Fan Connector 4-pin PWM
• Bearing Type Hydro Bearing
• Fan Rated Voltage 12 VDC
• Fan Rated Current 0.25 A
• Fan Power Consumption 3.0 W
• LED Type Addressable RGB LED
• LED Connector 3-pin(+5V-D-G)
• LED Rated Voltage 5 VDC
• LED Power Consumption 2.25 W（PUMP）/ 2.1 W（FAN×2）
• EAN 6.93341E+12
• P/N R-LE520-BKAMMN-G-1
• Overview
• The DeepCool LE520 all-in-one liquid cooler is equipped with new high-performance ARGB fans, thermal paste, and DeepCool’s new liquid cooler series design elements.
• Features:
• POWERFUL HEAT DISSIPATION: Thanks to an efficient micro-channel water block, thickened copper cold plate, and new high-performance ARGB fans, the LE520 achieves excellent heat dissipation of 220W TDP.
• NEW SERIES DESIGN: The LE520 features a new series pump with rounded corners, a square shape, bright ARGB, and additional durability. The low pump height of 52mm provides excellent compatibility for various ITX cases.
• HIGH-PERFORMANCE ARGB FANS: The included high-performance ARGB fans are vibrant, bright, and support various motherboard syncronizations. The fans provide maximum CFM and static pressure at higher RPMs while maintaining a quiet noise level of below 30dB at lower speeds.
• ANTI-LEAK TECHNOLOGY: The LE520 liquid cooler features DeepCool’s patented Anti-Leak Technology. The internal valve regulates pressure and will purge it when internal pressure exceeds atmospheric pressure; this leads to a longer useful life while reducing the possibility of leaks.
• SIMPLE AND SECURE: The installation is simple and compatible with the latest mainstream Intel and AMD processors.
